Hammer & BIT

We, SUNGWON Heavy Machinery, have been manufacturing and supplying rock,
soil drilling equipment and tools of DTH Hammers, Hammer Bits and Auger
Machines in Korea.

  • Hammer & BIT
  • Small & Medium-sized

DTH Hammer Detail Specification

Small &

Medium-sized

6” DTH Hammer

SWH140D, SWH140M, SWH140Q, SWH140S

Hammer Model
Bit Shank
Type		 SUNGWON
Atlas
Sandvik
Numa

Bit Dia. mm
Hammer Dia. mm
Cylinder
Bore		 mm
Piston
Stroke		 mm
Piston
Weight		 Kgs
Length
(Less Bit)		 mm
Weight
(Less Bit)		 Kgs
Connection
Type
Air
Consumption
CFM(m3/min)		 100 psi
7.0 Kg/cm2
150 psi
10.5 Kg/cm2
200 psi
14.0 Kg/cm2
250 psi
17.6 Kg/cm2
300 psi
21.0 Kg/cm2
350 psi
24.1 Kg/cm2
SWH140D SWH140M SWH140Q SWH140S

DHD360   QL60
  M60   SD6


152~190 152~190 152~190 152~190
140 140 140 140
118 118 118 118
100 100 100 100
20 22 20 20
1150 1130 1166 1166
104 106 104 104
API 3 1/2 Reg.Pin API 3 1/2 Reg.Pin API 3 1/2 Reg.Pin API 3 1/2 Reg.Pin

400(11.3) 400(11.3) 400(11.3) 400(11.3)
545(15.4) 545(15.4) 545(15.4) 545(15.4)
700(19.8) 700(19.8) 700(19.8) 700(19.8)
860(24.4) 860(24.4) 860(24.4) 860(24.4)
1025(29) 1025(29) 1025(29) 1060(29)
